Prestigio Data Racer I Kurzanleitung Seite 3

will appear in the file manager window as shown above.
On Macintosh machines, you can notice the disk icon in the
"Desktop" once you plug in the device into the USB port.
Before using the device, please format the device in to MAC
compatible file system (FAT32 format only).
In Linux OS, you can mount the device executing the
following instructions.
•
Check the device information in dev/s*, write down the
mount point.
•
Make a directory in /media (ex: mkdir/media/prestigio)
•
Then, execute sudo mount –t ntfs-3g/dev/sdb1/media/
prestigio –o force (if mount point was /dev/sdb1)
eSATA Port (For Windows System Only)
1. Please make sure the power switch is at OFF position
before connecting device to PC. Plug eSATA cable into
appropriate eSATA port and then connect the USB cable to
its appropriate USB port. The power is provided through USB
port in eSATA mode.
2. Slide power switch bar to ON position to turn on device.
When correctly connected, a Prestigio DATA RACER I icon
will be displayed in the file manager window.
NOTE:
•
eSATA compatibility may vary depending on user's
hardware configuration and operation system. Some eSATA
controllers may require system reboot process to be able to
recognize the new device.
•
The device is set up that eSATA connection as
first priority of data transmission mode. In case that
both eSATA and USB connection are established, eSATA
connection will be automatically designated as data
transmission purpose and USB connection will be for power
supplying purpose.
•
It is recommended to use Y shaped USB cable for
more secure and steady power supplying purpose.
Please plug in both ends of USB cable into appropriate
USB slots. Avoid using USB hubs for they may not provide
sufficient power.
DataRacer I
Warning: Before removing the USB device, make
sure the LED is not flashing. There is traffic going on between
the host computer and the USB device when the LED flashes
quickly. Do NOT remove the USB device at this moment.
Violation may cause data loss or even damages to the
Prestigio Data Racer I.
3. Using Turbo HDD USB Software
3.1 To Install Software
Warning:
•
Please log in as administrator before installing TurboHDD
USB Software if your operating system is Windows 2000/XP.
•
Please back up all critical data including TurboHDD USB
Software installation files before installing software. In case
of software data loss or corruption, please refer to
www.prestigio.com/product/downloads
downloading service.
1. Connect Hard Disk Enclosure device with PC with USB cable
provided.
2. An autorun window will pop up automatically. Please select
FNet Turbo HDD USB option to continue.
3. Click on the minimized window on toolbar to bring up the
User Account Control dialog box.
http://
for software
2
