Configuring Your SMC7804WBRA
Now that you have successfully configured your computer and
retrieved your new network settings from your SMC7804WBRA, you
are ready to configure the SMC7804WBRA's settings for your ISP.
1. Open your Web browser (Internet Explorer or Netscape
Navigator) and click the [Stop] button.
2. In the [Address] field type http://192.168.2.1
and press <ENTER>.
Note: For some browsers it may be necessary to include :88
after the management IP address. For example,
http://192.168.2.1:88
39
3. The SMC7804WBRA login screen will appear. Enter the default
password and click on [Login]. The default password is
smcadmin. For security reasons, you should assign a password
as soon as possible. Note that the login password is case-
sensitive.
4. On the home page of the SMC7804WBRA Web console,
click [Setup Wizard]. The automated setup process of the
SMC7804WBRA will take you through each step for setting
up your gateway.
