Contents of package

- Transformer
- Instructions
- Service and contact addresses
- Guarantee card
Important information
Before using or connecting the product for the first time, please read
these instructions for use carefully and keep them safe for future
reference. They are part of the product.
This product is designed to operate with Carrera Evolution racetrack
systems. Any other use is not deemed to be use for its intended
purpose and the manufacturer is not liable for any damage resulting
therefrom.
Operation is only permitted in dry rooms and the transformer must
not be operated in the open air.
The latest version of these instructions will be found on the Internet
page: www.carrera-toys.com
Description
The transformer is designed exclusively for the power supply to
Carrera Evolution cars racetracks. The transformer is fitted with
automatic short-circuit and overload protection on the secondary
side. In the case of a short-circuit or an overload, the transformer
switches off.
6

Electrical connection

1
Symbols
Connect the secondary side of the transformer to the EVOLUTION
connection rail as shown in flgure and plug the wall plug trans-
1
former into the mains socket.

Technical specifications

Mains input voltage:
Input current:
Output voltage:
Output current:
Output power:
This device is marked by "selective sort throught" symbol related to
sort through domestic, electric and electronic, waste. This means
the product must be treated by a specialized "sorting/collecting" sys-
tem in accordance with European directive 2012/19/EU, to reduce
the impact upon environment. For more precise information, please
contact your local administration.
Electronical product which are not going through special collect-
ing, are potentially dangerous for environment and human health,
because of dangerous substance.
Mains input voltage:
Input current:
Output voltage:
Output current:
Output power:
100 - 240 V/AC
0,8 A
14,8V/DC
2 x 1 A
2 x 14,8 VA
100 - 240 V/AC
0.8 A
14.8V/DC
2 x 1 A
2 x 14.8 VA
