Display Name - CTC Basic display Bedienungsanleitung

Display Name

101 Operation mode
102 Start stop difference
103 Discharge
104 Outdoor Temperature
105 Last error / present error
106 Brine out temp
107 Brine in temp
108 Inlet temp
109 Outlet temp
110 Suction temp
111 High Pressure
112 Low Pressure
113 Evaporation C
114 Condensing C
115 Suction SH
116 EV %
117 Capacity KW
118 Current A
119 Defrost Timer
120 Comp. Delay
121 Charge Pump
122 Brine p/fan out
123 Discharge SH
124 Max cond. K
125 Countdown s
Description
Addressing mode are displayed with
corresponding letter A1, A2, A3 ... A10.
"t" - For thermostatic control.
Fix return stop, shows set-value for stop
temperature,
Only in Fix Return Stop Mode. Other modes do
not show this.
Measured discharge temperature is shown here.
Measured outdoor temperature is shown here.
Displays the last / present alarm with the letter
"E" followed by the corresponding error code
Measured Brine Out temperature or Exhaust air
temperature is shown here.
Measured Brine In temperature is shown here.
Measured Inlet temperature is shown here.
Measured Outlet temperature is shown here.
Measured Suction temperature is shown here.
Measured Pressure in bar in high pressure side
is shown here.
Special function:
If up + dn is pressed for 3 seconds in this menu
and product = EA -> start a defrost. The defrost
should then run and stop according to its
function description.
Measured Pressure in bar in low pressure side is
shown here.
Measured Evaporator temperature from low
pressure conversion is shown here
Measured Condensing temperature from high
pressure conversion is shown here
Superheat is shown here
Expansion valve opening is shown here
Capacity from heat counter function is shown
here.
Current (from soft starter) is shown here
Timer defrost is shown here
Compressor delay (time until start permitted) is
shown here
Analogue output Y3. Charge pump modulating
output is shown here
Analogue output Y4 Fan/Brine pump modulating
output is shown here
Discharge SH - from EVD
Distance from max condensing, envelope.
Countdown before stopping compressor for out-
of-envelope
English
CTC EcoAir /
CTC EcoPart
EA + EP
EA + EP in fixed return
stop mode
EA + EP
EA
EA + EP
EA + EP
EP
EA + EP
EA + EP
EA + EP
EA + EP
EA + EP
EN
EA + EP
EA + EP
EA + EP
EA + EP
EA + EP
EA + EP
EA
EA + EP
EA + EP
EA + EP
EA + EP
Only 6 kW model
EA +EP
CTC Basic display
53
