GYS GYSFLASH 9.24 Betriebsanleitung Seite 8

START UP
1. Connect the charger to the battery.
2. Plug the charger to the mains (single phase 220-240Vac 50-60Hz).
3. Select the mode by pressing the
4. During the charge, the device indicates the charge progress. When indicator
Once indicator stays on, the battery is fully charged.
5. The charge can be interrupted at any time by unplugging the mains plug or pressing the
6. After charging, disconnect the charger from the mains, then disconnect the charger's connections from the battery.
CHARGE MODES
• Modes and Options description :
CHARGE Mode 6V (7.3V/9A) :
Mode designed to charge and maintain (floating charge) 6V batteries. 8 step automatic maintenance charge cycle.
CHARGE Mode 12V (14.6V/9A) :
Mode designed to charge and maintain (floating charge) 12V batteries. 8 step automatic maintenance charge cycle.
CHARGE Mode 24V (29.2V/6A) :
Mode designed to charge and maintain (floating charge) 24V batteries. 8 step automatic maintenance charge cycle.
REFRESH Option :
Option which add an extra step (step 7) to the charge cycle to restore deeply discharged batteries.
: this option is not recommended for charging sealed batteries.
Recommendation : Check the battery's water level and if necessary, perform with a Refresh charge.
• Charging curve :
The GYSFLASH 9.24 uses an 8 step charging curve which guarantees optimal performance for your battery.
1
U
I
Analysis
< 1s
1
Step : Analysis
Analyses the battery state (charge level, polarity inversion, wrong
battery...)
2
Step : Recovery (
Damaged elements recovery due to an extended deep discharge
algorithm.
8
GYSFLASH 9.24
button. After roughly 5 seconds, the charge starts automatically.
2 3 4
Recovery Test Desulfation
Max 5h < 1s Max 12h
4.5A / 3A)
blinks, the battery is ready to start the vehicle.
5 6
Charge Absorption
(If option activated)
Max 20h Max 8h
5
Step : Charge (
Fast charge with maximum current that can reach 80% charge
level.
6
Step : Absorption (
Constant voltage charge to reach a 100% charge level.
EN
button.
7 8
Refresh
Floating
1h - 4h no limit
9A / 6A)
7.3V / 14.6V / 29.2V)
