Default Settings; Before Configuration - Atlantis Land WebShare 111 Kurzanleitung

ENGLISH
WebShare Router ADSL2+ will carry on immediately a
diagnosis (20 seconds). Finished this the Led POWER and
SYS (eventually even the Led LAN, if connected to PCs) will
be fixed green. The Led ADSL, if suitably connected, at first
will be flashing , during the ranging process and then it will
remain fixed (necessary condition for using the Internet).

1.5 Default Settings

The WebShare Router ADSL2+ can be configured with your
Web browser. The web browser is included as a standard
application in following operation systems, UNIX, Linux, Mac
OS, Windows 95/98/NT/2000/Me, etc. The product provides
a very easy and user-friendly interface for configuration.

Before Configuration

This section describes the configuration required by LAN-
attached PCs that communicate with the WebShare Router
ADSL2+, either to configure the device, or for network
access. These PCs must have an Ethernet interface
installed properly, be connected to the WebShare
Router ADSL2+ either directly or through an external
repeater hub, and have TCP/IP installed and configured to
obtain an IP address through a DHCP server or a fixed IP
address that must be in the same subnet of the Wireless
ADSL Router. The default IP address of the WebShare
Router ADSL2+ is 192.168.1.254 and subnet mask is
255.255.255.0. The best and easy way is to configure the
PC (client DHCP) to get an IP address from the WebShare
Router ADSL2+.
Please follow the steps below for PC's network environment
installation. First of all, please check your PC's network
components. The TCP/IP protocol stack and Ethernet
network adapter must be installed. If not, please refer to MS
Windows relative manuals.
28
