For more detailed instructions on configuring and using
the
the online manual or Interactive guide on the CD.
Before beginning the configuration of the Router you have to
know the parameters of your subscription ADSL.
There are five ways ─ PPPoE, PPPoA, RFC1483 routed,
IPoA, RFC1483 Bridge─ for the device to have a public IP
address and then to access Internet. You have to check with
your ISP about which way is adopted.
VPI/VCI: Consult the telephone company to get the Virtual
Path Identifier (VPI) and Virtual Channel Identifier (VCI)
numbers. The valid range for the VPI is 0 to 255 and for the
VCI is 32 to 65535. The default value VPI is 0 and VCI is 32.
For BT (VPI=0, VCI=38)
NAT: The NAT feature allows multiple-user Internet access
for the cost of a single IP account. If you need to have a
public server or a public network, NAT has to be disabled.
Encapsulation Method: Be sure to use the encapsulation
method (LLC/SNAP or VC MUX) required by your ISP.
Gather the information as illustrated in the following table
and keep it for reference.
PPPoE
PPPoA
RFC1483
Bridged
WebShare Router ADSL2+, please refer to
VPI and VCI
VC-based / LLC-based multiplexing
Username and Password
Service Name
VPI and VCI
VC-based / LLC-based multiplexing
Username and Password
VPI/VCI
VC-based / LLC-based multiplexing
and for KC (VPI=1, VCI=50).
