Placing the system

Installation image:
TV
Sound Bar
VCR DVD player
Place the system as shown.
Remove the protective film covering the sound bar and
subwoofer before turn on the system.

System connections

Make sure to unplug the AC power lead before making any connections.
Subwoofer
PAIRING
AC INPUT
■
Sound bar and Subwoofer connection
Caution
●
Do not allow any objects to fall into or to be placed in the bass reflex duct.
●
Do not stand or sit on the sound bar/subwoofer. You may be injured.
Subwoofer
Wall socket
AC 220 - 240 V ~ 50/60 Hz
E-7
Notes:
●
The front panel of the sound bar is not removable.
●
The transmission distance of the wireless signal
between the subwoofer and sound bar is about 10m
(32 feet), but may vary depending on your operating
environment. If a steel-concrete or metallic wall is
between the subwoofer and the sound bar, the system
may not operate at all, because the wireless signal
cannot penetrate metal.
Caution:
●
Do not change the installation direction when the sound
bar is turned on.
●
Do not stand or sit on the sound bar and subwoofer as
you may be injured.
■
Placing the stand
Place the stand as shown.
Wall socket
AC 220 - 240 V ~ 50/60 Hz
Stand
Sound Bar
