Note: Although you can connect this Adapter to
many different Intermec printers, the illustration in
the next procedure shows the PF8t.
To connect the Adapter
1 Turn off the printer.
Connecting the Adapter to Your Printer
2 Plug the parallel port connector on the Adapter into the
parallel port on the printer.
3 Connect one end of an Ethernet cable to the 10BaseT/
100BaseTx Ethernet port on the adapter.
4 Connect the other end of the cable to an Ethernet port for
your network.
To connect to your network
• Turn on the printer. The LED on the Adapter flashes and
then turns off.
Parallel
port
Parallel
port
connector
10BaseT/100BaseTx
port
Ethernet
cable
