MOTION DET
OFF / ON
MOTION DET
DETECT SENSE
BLOCK DISP
MOTION AREA
AREA SEL
TOP
BOTTOM
LEFT
RIGHT
RETURN
•
CAMERA ID
OFF / ON
CAMERA ID
CAMERA
ABCDEFGHIJKLMNOPQRSTUV
WXYZ0123456789-#$%&?
()_`.:;<=> @^*./^*X+/
CHR1 CHR2
RETURN
•
SYNC
INT
Video synchronization displayed INT (Internal).
•
CAMERA RESET
Reset camera to default values.
Returns you to the previous menu.
•
BACK
Takes out of the menu
•
EXIT
Saves settings. You must click this setting to save any options
•
SAVE ALL
you changed in this menu or the camera will lose all your chan-
ges if it loses power.
111
OFF
ON
1 / 4
000
000
000
000
CLR POS
There are two ways for users to set up motion detection.
- DETECT SENSE:
Slide bar sets sensitivity of motion detection to 0 or 255
(maximum sensitivity).
- BLOCK DISP:
Settings are ON, OFF and ENABLE.
When ON is selected, the camera will show a mosaic in the
image when a motion is detected.
When ENABLE is selected, the user will see a grid pattern on
screen. Using the mini-joystick, each square on the grid can be
selected/deselected for motion detection.
When finished move the cursor to the lower right corner, hold
and release. The grid will disappear and this menu will return.
The camera will show a square in the image.
When a motion is detected, the square flashes.
- MONITOR AREA:
This option works with the AREA SEL selections, described
below. It enables the "areas" or turns them off.
- AREA SEL:
Lets you select up to 4 rectangular sections
(1/4, 2/4, 3/4 and 4/4), defined by the TOP, BOTTOM, LEFT and
RIGHT slide controls.
Camera ID shows a name on the screen as chosen.
Use Up/Down/Left/Right buttons to move around. Keep CHR1 setting. CLR will
clear info. POS allows position change.
22
