3. LCD Display

1 2 3 4 5
7 8

4. Equipment and Accessories Supplied

1. PMR-120TX
1) Radio (1)
2) Instruction Manual (1)
Optional Accessories : 1) AC Wall Charger
2. PMR-120TX-2
1) Radio (2)
2) Instruction Manual (1)
Optional Accessories : 1) AC Wall Charger
3. PMR-120TX-2CH
1) Radio (2)
2) Instruction Manual (1)
3) AC Wall Charger (1)
4) Rechargeable Batteries (2 packs)

5. Powering the transceiver

Your PMR-120TX Radio transceiver operates on three
AAA batteries. Alkaline batteries will provide slightly
better performance than rechargeable batteries.
When using rechargeable batteries, battery charging
time is typically 12-15 hours. (You are recommended
to charge two radios at the same time.)
1. Transmit Indicator
6
2. Busy Indicator (Upon
receiving a transmission)
3. Roger Beep Tone Indicator
4. Lock Indicator
5. CTCSS Subcode Indicator
6. Low Battery Level Indicator
7. Channel Number Display
8. Voice Activated
Tansmission indicator
9. Channel Scan
9
2) Rechargeable Batteries
2) Rechargeable Batteries
5
