Setup and Device Configuration

Stryker Endoscopy considers instructional training an integral part of the CrossFlow system� Your
Stryker Endoscopy representative will perform at least one in-service at your convenience to help
you set up your equipment and instruct you and your staff on its operation and maintenance�
Please contact your local Stryker Endoscopy representative to schedule an in-service after your
equipment has arrived and to receive ordering information�
Warning
To avoid risk of electric shock, ensure no liquid is present between connections�
Connection of wet components may lead to electric shock or an electrical short�
Caution
• When connecting or disconnecting a cable, hold the cable by its connector (its plug,
not the cord)� Failure to comply may result in damage to the cable or pump�
• Do not thread or twist the cable connector for insertion or removal� It is a push/pull
connector and may be damaged by twisting it into or out of place�
1� Locate the footswitch receptacle
2� Align the red dot on the footswitch cable connector with the red dot on the ring of the
receptacle�
3� Push the cable connector into the receptacle so the footswitch is securely connected to the
pump� Ensure the cable connector is fully pushed into the receptacle and there are no gaps
between them�
Note: When the device is powered on, the footswitch icon
of the pump's screen�
on the front panel of the pump�
will appear on the bottom
EN-5
