Putting the UI 770 into operation

Connection possibilities

An overview of the connection possibilities can be found on the
fold-out page.
Peripheral Connection on the
device UI 770
Headset Modular (RJ11)
A
B Dictaphone 3.5 mm jack
C Handset Modular (RJ11)
D Phone Modular (RJ11)
E Aux/PC Modular (RJ11)
Connecting the headset to the UI 770
A Connect the modular plug of the adapter cable to the headset
socket on the UI 770 until it locks in place.
Connecting the dictaphone to the UI 770
B Connect the 3.5 mm jack plug of the dictaphone connecting
cable to the dictaphone socket on the UI 770 until it locks into
place. Connect the 3.5 mm jack plug to your dictaphone.
Connecting the handset to the UI 770
C Pull the modular plug of the handset cable out of the telephone
and connect it to the handset socket on the UI 770 until it locks
into place.
Connection on the
peripheral device
Sennheiser Communications
Easy Disconnect
3.5 mm jack,
cable depends on dictaphone
socket
Modular (RJ11)
Depending on phone
3.5 mm jack
