INSTALLATIONGUIDE

1 Contents
The packaging should contain the following:
EN
• Fan
• 2 adapters, 1 x Ø98 mm and 1 x Ø118 mm
• Manual
• Accessory bag with 4 screws and plugs, a pull cord with
toggle, and insulation for the standard cable type (FK)

2 Installation

The fan can be installed on a wall or on a ceiling. See the
diagram below for installation dimensions. The fan must
not be installed in an environment where the temperature
exceeds 50°C. Attach an appropriate adapter to the fan's
chassis, Ø98 (1) for a Ø100 duct or Ø118 (2) for a Ø125 duct.
1
The fan can also be installed and
used without an adapter, so
that it is mounted completely
on the surface, e.g. in the case
2
of ducts less than Ø98.
When installing the fan, check that there is a seal between
the pipe/duct and wall/ceiling to prevent humid air from
penetrating the wall or ceiling. Use the accompanying
screw and plug, if necessary.
Min 120
45 45
x4
Alt. x4
Ø100 alt. Ø125
5
