Hydra Super-S3
1.4 Detailed View
1.4.1 Front View
LED/Button
Blue = Power on
• Green = Disk status normal
• Flashing green = Data access (e.g. read, write, system start up)
• Flashing orange = Rebuilding RAID array
• Red = HDD error
• OFF = Empty drive slot or interface cable is not yet connected
RAID mode confirmation button. Press and hold, turn on power, wait 5
CONFIRM
seconds and then release the button.
1.4.2 RAID Selector Switch
Switch Position
0
RAID 0 striping for 2-4 drives
1
RAID 1 for 2 drives or RAID 10 for 4 drives
2 Disk spanning for 2-4 drives (creates a single large volume)
3 RAID 5 for 3-4 drives
4 Non-RAID for 1-4 drives (drives can be accessed independently)
Note
Changing the RAID mode will erase all existing data. Make sure to backup all data first! For a
RAID array, hard drives with identical capacities are recommended.
1.4.3 Rear View
Label
Security lock slot
ON/OFF Power switch
eSATA External SATA port
FW800 FireWire 800 port
USB 3.0 USB 3.0 SuperSpeed port
DC 19V Power receptacle
Important
Always connect the interface cable and turn on your computer first, before turning on the
power. Otherwise, the drives will not spin up and the data cannot be accessed.
Description
Description
Description
