Specifications; Troubleshooting - Nebula Mars II Handbuch

Specifications
Specifications are subject to change without notice.
Power supply: DC 19V 3A
Power consumption: < 57W
Standby power consumption: < 0.5W
Display technology: 0.3 inch 1280*720p DLP
Light source: RGB LED
Projection image size: 30 - 150 inch
Resolution: 1280 x 720 pixels
Brightness: 300 ANSI Lumens/ 1,500 lm
Contrast ratio: 1000:1
Projection ratio: 1.2
Speaker drivers: 10 w x 2
Bluetooth: V4.0
Built-in battery type: Li-Polymer
Capacity: 12500 mAh 3.8V
Video play duration: 4 hours
Music play duration: 30 hours
Remote control batteries: CR2032 x 2
Operating temperature: 0°C to 35°C / 32°F to 95 °F
Operating humidity: 15% ~ 85% (non-condensing)
Storage temperature and humidity: < 65°C / 149°F, < 90% humidity
Dimension (W*H*D): 122 × 138 × 178 mm / 4.8 × 5.4 × 7 in
Weight: 1,483 g / 52.3 oz
16

Troubleshooting

① Fail to power on by the remote control?
Make sure that the device is connected to the power supply.
Slide down the lens cover.
② Fail to power on by sliding down the lens cover?
Make sure that the device is connected to the power supply.
Slide up the lens cover and wait for 10 seconds, then try again.
③ The remote control doesn't work?
Remove the battery insulation tab to activate the remote control
batteries.
Replace new batteries.
④ Blurred image?
You can either slightly move the projector or press the navigation
buttons to focus the image.
⑤ Reversed projection image?
On the home menu, select [Settings] > [Projector mode] and switch to
the correct state.
17
