F1D208-OSD_EU_man.qxd 4/20/00
CONSOLE CONSOLE
Keyboard,
mouse and
monitor
AutoScan Mode:
In AutoScan mode, the OmniView
next. This time interval is set in the On-Screen Display menu.
NOTE: There is no mouse or keyboard control in this mode. This is necessary to prevent errors. Otherwise, if the user
is moving the mouse or using the keyboard when the OmniView
flow is interrupted and will cause erratic mouse movement and/or the wrong characters to show up when
using the keyboard.
To get out of AutoScan mode, press the SPACEBAR.
On-Screen Display Menu Control:
To get into the On-Screen Display (OSD) menu, press SCROLL LOCK, SCROLL LOCK, SPACEBAR. Immediately, the
OSD overlay screen appears. This screen is generated by the OmniView
or running software in any way.
4:37 PM Page 12
Usage
(continued)
Bank 0 (Master)
1
Bank 1 (slave)
9
Bank 2 (slave)
17
etc...
Bank F (slave)
121
Enable AutoScan mode
™ MATRIX remains on one port for a number of seconds, before switching to the
Enable the On-Screen Display Menu
12
2 3 4 5 6
10 11 12 13 14
18 19 20 21 22
122 123 124 125 126
™ MATRIX switches to the next port, data
™ MATRIX, and does not affect your computers
7 8
15 16
23 24
127 128
