Display Meaning
PulSE CH Remote readout mode
(optional)
123 A Primary address for
MBus option
2345678 K Owner number, 7 digit
18.02.08 F0 Time stamp for F0
Advance warning
3- 01 FW Firmware version
31.12.07 V Reference date, previ-
ous year
0034321 kWh Energy previous year
on reference date
00923.12 m³ Volume previous year
on reference date
12 Fh Downtime hours previ-
ous year
- -.- -.- - C Code input for parame-
terisation
01.06.08 M Day saved in month 1-
15
Key pressed more than
3s:
0034321 kWh Energy previous month
on reference date
00923.12 m³ Volume previous month
on reference date
12 Fh Downtime hours previ-
ous month on reference
date
Parameterizing loop
Display Meaning
01.01. - - S Annual reference date (dd,mm)
24.07.08 D Date (DD.MM.YYYY)
15.33.06 T Time (hh.mm.ss)
2345678 K Owner No. or MBus secondary
address)*
123 A MBus primary address
Ft + Downtime reset
Nb - - - - - Return to normal operation
The following list describes how you can switch between
the loops:
18/63
ista International GmbH - Grugaplatz 2 - 45131 Essen
▪
User loop ↔ Service loop
▼
▪
→: Press button for 10 sec.
Info
▪
←: Press button for 3 sec. (except from field code input
and day saved in month)
Info
▪
Service loop -> Parameterising loop
Info
▪
→: Press button for 3 sec. in Code Input field, then en-
Info
ter the meter date
▪
←: Short press on button in field to return to normal op-
Info
eration
Previous
year
Installation
Previous
year 1. Flush pipeline according to DIN/EN. Observe the
country specific regulations!
Previous
year
2. Note the direction of flow and compare with the arrow
Previous on the meter.
year
3. Close the shut-off devices in front and behind the in-
stallation site.
4. Dismount adapter, if neccessary.
Previous
5. Clean sealing surfaces.
month
6. Only insert a new profile sealing.
7. Insert new seal.
8. Note the direction of flow and compare with the arrow
Previous
on the meter.
month
9. Mount meter.
Previous
month
10. Tighten all screw connections(in case of flange con-
Previous nection tighten nuts crosswise).
month
11. Install temperature sensors, depending on version,
into tees, ball valves or immersion sleeves.
a) Wall mounted ALU (optional)
1. Pull the calculator off the attachment.
2. Unscrew the attachment with a screw driver.
3. Prior to drilling, check that there are no electricity ca-
bles, gas or water pipes below the surface at the instal-
lation site.
4. Drill hole into the wall (6 mm).
5. Insert dowels.
6. Attach the mounting plate to the wall.
7. Attach the calculator to the installation base from
above.
