3. dEViCE inSTALLATiOn

Warning of electrical dangers, for the lamp and the head:
The device must be installed by specialist technicians.
During the installation, the general power source to which the lamp must be con-
nected must be disconnected.
For the connection use a terminal block conform to the EN 60998-2-1 or EN60998-2-2
E.G: Cembre Z205-1 Zetamini serie
Check the label data before installation.
Notes for installation
The lamp's operation or safety does not depend on the polarity or the power source.
For which, inversion of the power cables poses no risk of malfunctioning.
Notes for installation
Suspend/lift the lamp using the outer casing. Do not apply force on the panel diffu-
ser (white).
3.1

diMEnSiOnS

Fig. 1
22
