Front Panel Operation - Datamax I-Class Kurzanleitung

Front Panel Lights and Buttons
Escape Button
Up Arrow Button
Down Arrow Button
Enter Button
Menu Button
Pause Button
Feed Button
Cancel Button
Test Button
Ready Light
Stop Light
Error Light

Front Panel Operation

ESC:
Arrow Up:
Arrow Down: Moves to the previous item in the menu tree, (decrease
Enter:
Menu:
Pause:
Feed:
Cancel: Cancels a job and pauses the printer.
Test:
Ready: On indicates ready, blinking indicates menu mode.
Stop:
Error:
Moves to the previous menu level.
Moves to the next item in the menu tree, (increases values).
values).
Selects a displayed item or value.
Toggles between the ready mode and menu mode.
Toggles the pause condition.
Feeds paper.
Enables the quick test mode.
On indicates paused state.
On indicates a fault. To clear a fault press the feed button.
47
