Chapter 4
User interface & configuration
To get access to the control and configuration settings, the MTX should be connected to a
computer or an Ethernet LAN network. For more information about network connections
and settings, see IP basics in chapter 6.
The standard (factory default) IP address of the MTX is 192.168.0.192, make sure this
address is within the IP range of the connected Ethernet LAN network (subnetmask
255.255.255.0). If the default network address is not within range of your LAN network,
contact your network specialist. The network address can be changed with the Standard
Web Based User Interface but therefore a network connection has to be made first!
Any device (PC, Laptop, PDA or even a Smartphone) with a web browser and the
Macromedia Flash 8.0 plug-in (or higher) installed, can be used to control the web based
user interface.
For mobile devices, such as PDA's, smartphones or even iPhones or iPads, special
applications are developed to control the standard functions of the MTX Matrix.

Open the user interface

Start your default web browser and enter the IP address of the embedded web server of the MTX
in the address bar. (The factory default IP address is http://192.168.0.192).

Login screen

First the login screen will be displayed.
A password should be entered to get access to the web interface of the MTX matrix.
There are two different access levels, administrator level and user level.
If you log-in using the administrator password, you get access to all functions and
configuration options of the MTX Matrix (The factory default password for administrator
acces is "MTX").
When you log-in using the user password, you only get access to the basic functions of
the MTX matrix, such as changing the volume and changing the routing for a particular
output zone. (The factory default password for user acces is "user").
After the right password is entered, click the "OK" button, and you will be redirected to
the main screen of the MTX interface.
NOTE
The passwords can be changed in the Configuration >> Password settings menu (Only
administrator)
23
