LFS-75DMX QRG
Control Panel
Description

Menu Options

Main Level
DMX Address
Manual Mode
Display
Temperature
Reset
Load

DMX Linking

Starting Address

Button Function
<MODE/ESC> Exits from the current menu or function
Navigates upwards through the menu list and increases
<UP>
the numeric value when in a function
Navigates downwards through the menu list and
<DOWN>
decreases the numeric value when in a function
Enables the currently displayed menu or sets the currently
<ENTER>
selected value into the selected function
Programming Levels
d001–d512
CoLr Co00–Co17
CoSP CP00–CP63
MAN
dimm L000–L255
SHUt S000–S100
diS
rdiS
tC__
rESt
LoAd
The LFS-75DMX can work with a DMX controller when linked by DMX
serial connections. Instructions for connecting and configuring this product
for DMX operation are in the User Manual. If you are not familiar with
DMX, download the DMX Primer from www.chauvetlighting.com.
To ensure full access to all channels in each DMX mode, the highest
recommended DMX address is 509.
Sets the DMX starting address
Color wheel
Color scroll speed
(when CoLr is set to Co16 or Co17)
Dimmer (0–100%)
Shutter speeds (slow to fast)
Normal display
Inverted display
Displays LED temperature in Celsius
Resets product
Loads factory defaults
