Device name
1
This is the name of the device that can have its settings
changed in the current Device View.
Change device name
2
Edit the device name.
Sampling frequency
3
Set the sampling frequency.
Bit depth
4
Set the bit depth.
Latency setting
5
Set the latency.
Use the following guidelines to change the latency setting.
Selectable
Connected network setup guideline
latency value
There are up to 10 layers of gigabit switch
1msec between transmitting device and receiving
device.
There are 100Mbps transmitters or receivers
2msec
connected to a Gigabit network.
Use this maximum selectable latency value
5msec
when creating a large-scale network.
CAUTION
Changing the name of a device will clear audio routing
i
settings. For this reason, we recommend changing device
names to names that are easy to identify before setting
audio routings.
Depending on network connection conditions, setting
i
the latency to a value higher than the guideline might be
necessary.
NOTE
Set the sampling rate and bit depth to the same values
i
as the other Dante devices that send and receive audio
signals. Also set the unit in which the IF-DA2 is installed to
the same values.
When using a switched (daisy chain) connection, which
i
does not use a switching hub, set the latency according to
the number of Dante devices that signals pass-through as
shown below.
8 Switched (daisy chain) connection example
Passes through 2 devices
Transmitting
1st device
e
device
Passes through 1 device
Transmitting
1st device
e
device
IF-DA2 or other
2nd device
e e
receiving device
IF-DA2 or other
receiving device
TASCAM IF-DA2
11
