Operation

Specifications

CAUTION: MAKE SURE HEAT SHIELD AND FEED TABLE
Operating Speed
ARE IN THE PROPER POSITION TO OPERATE THE UNIT.
Dimensions (W x L x H)
Move the Main Power switch to the 'ON' ( ) position (figure 1).
1
Weight
With the main power switch in the 'ON' ( ) position, the
Voltage
laminator can be turned on or off using the standby switch ( )
located on the control panel. When the standby switch is activated Current
the red power indicator ( ) will illuminate. The laminator is now
Power
heating.
BTU/kCal
Warm-up Time
2 Use the lamination guide on the feed table to select the correct
laminating temperature for the film gauge and media that you are
Electrical requirements - Refer to the serial plate located on the rear of the
laminating. The guide will provide a good starting point. You may
laminator for the specific electrical rating applicable to the unit.
need to adjust the temperature up or down slightly to
accommodate the finish or thickness of the media.
Lamination Guide
3 When the laminator reaches operating temperature, the green
ready indicator ( ) on the control panel will illuminate.
Material
4 Position the item(s) to be laminated on the feed table.
Copy Paper
Glossy Paper
Move the RUN / STOP / REVERSE SWITCH ( ) to the 'RUN'
5
Photo Paper
( ) position.
This chart is for reference only. Actual Temperature setting will vary depending on
6 Slide the item(s) to be laminated into the nip rollers.
media thickness and ink coverage.
7 When the laminated item(s) exit(s) the rear of the laminator, move
the RUN / STOP / REVERSE SWITCH ( ) to the 'STOP'
( ) position.
Laminating Tips
8 Use the Rear Slitter located at the back of the laminator to
• Do not attempt to laminate abrasive or metal items such as staples
separate the laminated item(s) from the film web.
or paper clips as they will damage the heat shoes and rollers.
• Do not force items into the nip area of the rollers. An item that is not
easily drawn into the laminator is probably too thick to laminate.
Clearing a Film Jam (Wrap-Up)
• Wrinkles may result if an attempt is made to reposition an item once
the rollers have grasped it.
Film jams may occur if the laminator is not positioned to allow exiting
film to drop freely to the floor. Accumulation of laminate as it exits the • Do not stop the laminator before an item has completely exited the
rear of the laminator. Even a momentary stop will cause a mark (heat
laminator may cause film to wrap around the roller, causing a jammed
line) to appear on the laminated item.
condition.
Adhesive will be deposited on the heat shoes and rollers if:
To clear a jam it is necessary to rotate the rollers in a reverse direction.
• Only one roll of film is used. The top and bottom rolls must be used
To clear a jam:
for problem free lamination.
1 Immediately stop the laminator by moving the RUN / STOP /
• One or both rolls of film are allowed to run completely off the core.
REVERSE SWITCH ( ) to the 'STOP' ( ) position.
Remove the feed table and heat shield.
2
3 Cut the top and bottom film webs.
4 Grasp the loose ends of the web and pull straight out. Install the
feed table with the loose ends of the web on top of the table.
5 Move the RUN / STOP / REVERSE SWITCH ( ) to the
'REVERSE' ( ) position and guide the film out of the laminator.
6 When the film has cleared the heat shoes, move the RUN / STOP
/ REVERSE SWITCH ( ) to the 'STOP' ( ) position.
7 Thread the film per section Film Loading and Threading.
8
Page 8

Troubleshooting Guide

Ultima35 EZLoad
SYMPTOM
1m/min
430 x 460 x 203mm • POWER indicator does not illuminate when
Main power switch is in the 'ON' ( )
16kg
position.
230V ~ 50Hz
4.5A / 230VAC / 50Hz
1035W
3,534.51 BTU/hour / 890.68 kCal/hour
1 minute
• Laminated items are wrinkled.
• Laminated items are wavy.
42.5mic 75mic 125mic 175mic 250mic
• Laminated items are cloudy.
5 - 7 4 - 7 4 - 7 4 - 6 4 - 6
6 - 8 5 - 8 5 - 7 5 - 7 4 - 6
6 - 9 6 - 8 5 - 8 5 - 8 4 - 7
• Unsatisfactory adhesion to media.
• Not running
Guarantee
Operation of this machine is guaranteed for two years from date of
purchase, subject to normal use. Within the guarantee period, GBC will
at its own discretion either repair or replace the defective machine free
of charge. Defects due to misuse or use for inappropriate purposes are
not covered under the guarantee. Proof of date of purchase will be
Register this product online at www.gbceurope.com
POSSIBLE CAUSE CORRECTIVE ACTION
Standby switch on control panel is not Push standby switch on control panel.
activated.
Laminator is not connected to electrical Insert plug into appropriate receptacle.
supply.
Fuse is blown. Replace fuse.
Tension on top or bottom supply roll is too Close lever completely.
loose. Film holder lever is not closed.
Excessive heat. Reduce temperature by turning temperature control
counter-clockwise.
Insufficient heat. Increase temperature by turning temperature control
clockwise.
Ready light is not illuminated. Wait for the ready light to illuminate.
Insufficient heat. Increase temperature by turning temperature control
clockwise.
Ready light must be illuminated.
Laminated item may not be suitable for The composition or finish of the media may not be
thermal lamination. compatible with the thermal lamination process.
Latch not properly locked (power to control Close latch
panel turned off)
required. Repairs or alterations made by persons not authorised by GBC
will invalidate the guarantee. It is our aim to ensure that our products
perform to the specifications stated. This guarantee does not affect the
legal rights which consumers have under applicable national legislation
governing the sale of goods.
