8. Cutting operation
(1) As shown in Fig. 17 the width of the saw blade is the
width of the cut. Therefore, slide the workpiece to the
right (viewed from the operator's position) when
length is desired, or to the left when length
desired.
(Only Model C10FCH)
If a laser marker is used, align the laser line with the
left side of the saw blade, and then align the ink line
with the laser line.
(2) Once the saw blade reaches maximum speed, slowly
push down the handle while pushing the lock lever
(C) and bring the saw blade in the vicinity of the
material to be cut.
(3) Once the saw blade contacts the workpiece, push the
handle down gradually to cut into the workpiece.
(4) After cutting the workpiece to the desired depth, turn
the power tool OFF and let the saw blade stop
completely before raising the handle from the
workpiece to return it to the full retract position.
CAUTION
For maximum dimensions for cutting, refer to
"SPECIFICATIONS" table.
Increased pressure on the handle will not increase the
cutting speed. On the contrary, too much pressure
may result in overload of the motor and/or decreased
cutting efficiency.
Confirm that the trigger switch is turned OFF and the
power plug has been removed from the receptacle
whenever the tool is not in use.
Always turn the power off and let the saw blade stop
completely before raising the handle from the
workpiece. If the handle is raised while the saw blade
is still rotating, the cut-off piece may become jammed
against the saw blade causing fragments to scatter
about dangerously.
Every time one cutting of deep-cutting operation is
finished, turn the switch off, and check that the saw
blade has stopped. Then raise the handle, and return
it to the full retract position.
Be absolutely sure to remove the cut material from
the top of the turntable, and then proceed to the next
step.
9. Miter cutting procedures
(1) Loosen the side handle and push the lever for angle
stoppers. Then, adjust the turntable until the indicator
aligns with desired setting on the miter scale (Fig. 18).
(2) Re-tighten the side handle to secure the turntable in
the desired position.
NOTE
Positive stops are provided at the right and left of the
0° center setting, at 15°, 22.5°, 31.6° and 45° settings.
Check that the miter scale and the tip of the indicator
are properly aligned.
Operation of the saw with the miter scale and indicator
out of alignment, or with the side handle not properly
tightened, will result in poor cutting precision.
CAUTION
Never remove the side handle; use of the tool without
it would be hazardous.
To prevent an accident or personal injury always firmly
tighten the miter handle.
10. Bevel cutting procedures (Fig. 19)
(1) Loosen the clamp lever and bevel the saw blade to
the left.
(2) Adjust the bevel angle to the desired setting while
watching the bevel angle scale and indicator, then
secure the clamp lever.
WARNING
is When the workpiece is secured on the left or right
side of the blade, the short cut-off portion will come
to rest on the right or left side of the saw blade. Always
turn the power off and let the saw blade stop
completely before raising the handle from the
workpiece.
If the handle is raised while the saw blade is still
rotating, the cut-off piece may become jammed
against the saw blade causing fragments to scatter
about dangerously.
When stopping the bevel cutting operation halfway,
start cutting after pulling back the motor head to the
initial position.
Starting from halfway, without pulling back, causes
the safety cover to be caught in the cutting groove of
the workpiece and to contact the saw blade.
11. Compound cutting procedures
Compound cutting can be performed by following the
instructions in 9 and 10 above. For maximum
dimensions for compound cutting, refer to
"SPECIFICATIONS" table.
CAUTION
Always secure the workpiece with the right hand side
for compound cutting. Never rotate the table to the
right for compound cutting, because the saw blade
might then contact the clamp or vise that secures the
workpiece, and cause personal injury or damage.
12. Cutting long materials
When cutting long materials, use an auxiliary platform
which is the same height as the holder (optional
accessory) and base of the special auxiliary
equipment.
Capacity: wooden material (W × H × L)
120 mm × 40 mm × 1000 mm
13. Installing the holders (Optional accessory)
The holders help keep longer workpieces stable and
in place during the cutting operation.
(1) As indicated in Fig. 20, use a steel square for aligning
the upper edge of the holders with the base surface.
Loosen the 6 mm wing nut. Turn a height adjustment
bolt 6 mm, and adjust the height of the holder.
(2) After adjustment, firmly tighten the wing nut and
fasten the holder with the 6 mm knob bolt (optional
accessory). If the length of Height Adjustment Bolt 6
mm is insufficient, spread a thin plate beneath. Make
sure the end of Height Adjustment Bolt 6 mm does
not protrude from the holder.
14. Stopper for precision cutting (Stopper and holder are
optional accessory)
The stopper facilitates continuous precision cutting
in lengths of 280 mm to 450 mm.
To install the stopper, attach it to the holder with the
6 mm wing bolt as shown in Fig. 21.
15. Confirmation for use Crown molding vise, Crown
molding Stopper (L) and (R) (Optional accessory)
(1) Crown molding Stopper (L) and (R) (optional
accessories) allow easier cuts of crown molding
without tilting the saw blade. lnstall them in the base
both-sides side to be shown in Fig. 22. After inserting
tighten the 6 mm knob bolts to secure the Crown
molding Stoppers.
