22
Pin/contact
26
27*
28*
29
30*
31*
32
33*
34*
35
36
37
38
39
40
*Short pins in the mating backpanel connector.
Barracuda 9FC Installation Guide, Rev. A
Signal name
Ground
+CH2_in
–CH2_in
Ground
+CH1_out
–CH1_out
Ground
+CH2_out
–CH2_out
Ground
SEL_2
SEL_1
SEL_0
Reserved NC
5 Volts charge
Signal type
Diff. PECL input pair
Diff. PECL output pair
Diff. PECL output pair
TTL input
TTL input
TTL input
