Barracuda 9FC Installation Guide, Rev. A
Notes:
Mounting holes three on each side, 6-32 UNC. Max screw
[1]
length into side of drive is 0.15 in. (3.81 mm).
Mounting holes four on bottom, 6-32 UNC.
[2]
Max screw length into bottom of drive is 0.15 in. (3.81 mm).
Keep-out zone for any components on backplane.
[3]
Connector is centered on module and flush with end of base.
[4]
A
B
C
D
E
F
G
H
J
K
L
M
N
P
R
Inches
5.760
max
4.010
max
1.026
max
.620
ref
±
4.000
0.010
.250
+
0.010
–
0.005
±
1.750
0.010
±
3.750
0.010
±
2.370
0.010
±
1.750
0.020
0.181
+
0.018
–
0.013
1.646
max
±
1.625
0.020
.1215
max
.1215
max
Millimeters
146.304
max
101.854
max
26.060
max
15.748
ref
±
101.600
.25
6.350
+
.25
–
.12
±
44.45
.25
±
95.250
.25
±
60.200
.25
±
44.450
.50
4.590
+
.45
–
.33
41.800
max
±
41.280
.50
3.080
max
3.080
max
17
