2. INTENSITY knob
Use this knob to set the variation
range of modulation. With delay
types PITCH and KOSMIC, the
INTENSITY setting specifies the
pitch variation.
9. EFFECT
1. BALANCE knob
Use this knob to adjust the
volume balance of the direct
sound that's being input and
the delay sound that passes
through the delay module.
10. OUTPUT ATTENUATOR
1. OUTPUT ATTENUATOR
switch
Use this switch to select the
output level. Adjust this switch
according to the device that's
connected to the output jack of
the SDD-3000 PEDAL.
–20dB: Audio devices and am-
plifiers for musical instruments.
–10dB: Semi-professional devices
and other audio equipment.
+4dB: PA mixers and other
professional equipment.
12
3. FREQUENCY knob
Use this knob to set the
oscillating frequency of the
LFO for modulation.
Tip: When the FREQUENCY
knob is set to 0, the INTENSITY
knob becomes the direct modu-
lation source.
1. OUTPUT ATTENUATOR
1. BALANCE knob
switch
