INSTALLATION

6
1. When installing the outdoor unit, make
sure that the location you wish to install it
is dry. It is important that the camera or the
electronics do not get wet.
2. Drill holes in the wall, insert the wall plugs in
the holes. Place the bracket and tighten the
screws.
3. Connect the wires.
4. Mount the outdoor unit on the bracket. Make
sure it is properly secured.
EN
INSTALLATION
1. Choose a suitable place.
2. Mount backing plate of indoor-monitor by drilling
holes in the wall, and screwing the backing plate
firmly, making provision for the cable to pass
through.
3. Connect the wires to screw terminals as per
diagram.
4. Insert the bracket into the slots of indoor-monitor.
EN
