ubbink Azura Montageanleitung Seite 9

WARRANTIES - After-sales service
Swimming pool 200x350 - H71 cm
Warranty conditions:
The swimming pool must be assembled within 48 hours of the package being opened.
For the warranty to be valid, a concrete slab must be in place.
Our warranty covers only the replacement of defective parts. It in no way covers demands for compensation or damages. The general warranty does not apply in the following circumstances:
• Use of the equipment in a way which is not in accordance with the instructions.
• Damage incurred as a result of bad handling during and after assembly.
1) Pump : 2 year warranty (electrical problems) under normal usage conditions. The following are not covered by the warranty: Deterioration by abrasion or corrosion, deterioration due to a faulty connection,
equipment dismantled or repaired by a third party, parts breaking (pump base, prefilter cover, hose connector...), running the pump when dry. The warranty is void if the electrical cable and/or the plug are
replaced, removed or damaged
2) Liner : 2 year warranty under normal usage conditions. The following are not covered by the warranty: Punctures, holes, tears, stains (treatment products directly in the water), stains due to algae growth, stains
due to decomposition of foreign bodies in contact with the liner, stains and decolouration due to oxidising products, colourfastness and wear due to rubbing on various surfaces. Deformation of the liner left without
water for more than 24 hours (never empty your swimming pool completely).
3) Filter : 2 year warranty on non-installed products: tank, drainage plug, collar, multiport valves... The following are not covered by the warranty: Watertightness problems following use of pressure greater than the
maximum authorised pressure. (ref. filter notice).
4) Skimmer : 2 year warranty on the seal joints.
5) Wooden structure : 10 year warranty against corrosion and insect attack. The following are not covered by the warranty: Changes in wood colour due to weather, natural deformations (splitting, cracks which
in no way impair the mechanical performance of the wood). The warranty does not cover assembly or storage faults producing deformations in the wall panels (if assembled a long time after the package being
opened), deformation of the planks which in no way impairs the mechanical performance of the swimming pool.
IMPORTANT : The after-sales service will be available only at point of sale.
Essential records for claiming the warranty: - Till receipt/proof of purchase.
- Warranty slip.
- Reference number of the faulty part.
Shop :
City :
Contact department :
Direct tel :
Code Ref. Désignation
M
7504334 Plank 45 x 145 x 1480 mm
MSE
7504335 Upper plank 45 x 135 x 1480 mm
MSS
7504336 Upper skimmer plank 45 x 135 x 1480 mm
MSI
7504337 Lower skimmer plank 45 x 145 x 1480 mm
MR
7504338 Water jet plank 45 x 145 x 1480 mm
PA
7514841 P1 corner post 100 x 120 x 630 mm
PJ
7514842 P2 joint post 100 x 120 x 630 mm
B-2
7514743 Notched planking 45 x 170 x 1942 mm
B-1
7514744 Un-notched planking 45 x 170 x 3263 mm
PF
7504359 Finishing profile 630 x 60 x 10 mm
MGE-G
7514745 Pine edging 28 x 145 x 1679 mm
MGI-G
7514746 Pine edging 28 x 145 x 1979 mm
MGI-P
7504466 Pine edging 28 x 145 x 3493 mm
MGE-P
7504467 Pine edging 28 x 145 x 3493 mm
C
7514048 Console edging 45 x 230 x 170 mm
7514767 Reinforcing strip
7514114 Sacrifice part 45 x 135 x 280 mm
7514149 Sandbag 25 kg
R
7514015 Hung 2.06 ml hanging rails
JA
7514843 Galvanised steel corner joint 100 x 637 mm
Angle reinforcement junction in galvanized steel
JAR
7514844
118 x 637 mm
JD
7514845 Galvanised steel straight joint 119 x 630 mm
7504397 Pump POOLMAX
S
7514019 Skimmer large
7514030 Ground protection felt
7514704 Filter
7504410 Flexible pipe, 1 x 8 m
90 degree connection tube
NOTICE 200X350 - H71-NB.indd 6
NOTICE 200x350 - H71-2015-I.indd 9
Client :
Address :
City :
Tel :
Qty Qty
Hardware kit
7514757
parcel ASS
Code Code Réf. Ref. BREAKDOWN OF THE HARDWARE KIT DÉTAIL DU KIT QUNCAILLERIE
22
5
A1 A1
7514516 7514516 Sachet consoles + renforts Console + reinforcer bag
1
A3 A0
7514638 7514267 Sachet consoles + renforts Console + reinforcer bag
1
C1 C1
7514372 7514372 Sachet rails - Hung Hung rails bag
1
DMP0 DMP1
7514457 7514617 Sachet vis margelles Edging screws bag
4 G K3
7514146 7514847 Sachet fixation echelle bois Post fasteners bag
2 J1 M
7504411 7514276 Sachet fixation poteaux Wooden cache planks fastener bag
2 K1
7504413 Sachet fixation poteaux
7514271
2 P1
Sachet fixation sabot metallique
7514273
6 M
7514276 Sachet fixation planches caches bois
2
2
2
2
MGI-G
12
1
2
1
7
R
MGE-G
4
2
4
MSE
1
1
1
1
1
M
1
MR
PF
5
8
7514840
1
Qté Qté Qté Qté
Colis parcel SAV ASS
2 1
1 1
2 1
2 1
1 1
1 1
1
2
1
MGI-P
JD
R
B-2
I / 15-I
Blue liner 50/100 200x350 H71 cm 1
JA
JAR
S
MGE-P
MSI
MSS
C
PA
19/01/15 13:56
07.12.15 09:09
B-1
