SPARE PARTS OF FILTER
Nº CODE
1 09921R001
2 720R1750057
SPARE PARTS OF PUMP
Nº CODE
1 09096R0130
2 09096R0104
3 09096R0140
4 09096R0300
5 09096R0162
6 09096R0163
7 09096R0105
8 09096R0120
9 09096R0110
10 70107R06030
11 70107R06020
12 09098R3000
13 09096R0301
14 09096R0302
1
DESCRIPTION
Filter body ø500
O-ring cover
DESCRIPTION
Pre-filter lid
Pre-filter lid seal
Pre-filter
Lid handle
Handle shaft
Handle securing clip
Drain plug
Pump body
Pump base
Screw M6 x 30 DIN 912
Screw M6 x 20 DIN 912
Pump motor
Fan
Fan cover
3
2
Nº CODE
3 00555R0300
4 05872R0201
Nº CODE
15 70132R04010
16 09096R0309
17 09096R0307
18 09096R0310
19 09096R0306
20 09096R0305
21 09096R0210
22 09096R0201
23 09096R0204
24 09098R0230
25 09096R0202
26 09096R02207
27 09096R0203
28 09096R0101
-8-
4
DESCRIPTION
Filter ring
1 1/2" Top valve
DESCRIPTION
Fan cover screw
Cable gland
Conection box lid screw
Condenser
Connection box lid
Connection box seal
Pump body flange
Breakwater
Mechanical seal
Pump turbine (Ø500)
Diffuser seal
Diffuser
Turbine securing plug
Pump body seal
