Modster TRAINSTAR ASCENT AN-269468 Betriebsanleitung Seite 16

User Manual
7. Install the landing gear to the fuselage,
using 2pcs PM3*30 screws and 2pcs 10*3.2 washers.
9. Install the control horn to servo on main wing, using
a PWA2.3*4 screw. Repeat this step to the servo at the
other part of main wing.
11. Connect the push rod to link the control horn and
servo arm for horizontal tail and vertical tail.
16
MODSTER Trainstar Ascent
8. Install hinge control horns to reserved position on main
wing ailerons. Make sure the two plastic parts are well
secured to the foam.
10. Install the push rod to connect control horn and servo
arm for each side of main wings.
12. Install the motor shaft adaptor, propeller and spinner
by the order as shown above.
