Hedge And Shrub Trimming Operation; Basic Hedge Trimming Operation; Working Position - Echo HCA-236ES-LW Bedienungsanleitung

Hedge and shrub trimming operation

Basic hedge trimming operation

NOTE
This product is designed to cut shrubs and hedges with branches no larger than 6 mm in diameter.
When starting to trim, run the engine at full throttle. Cutting at less at than full speed can damage the clutch by allowing it to
slip. When you do not conduct trimming or cutting work, do not run the engine at full throttle.
1. Throttle trigger
2. High speed
3. Idling
Hedge and shrub trimming operation
Pulling the throttle trigger after the engine is started will cause
the engine speed to rise and the cutter blades to start moving.
Adjust the engine speed depending on, for example, the
amount of the hedges to be cut.

Working Position

Hold the control handle with your right hand, and the shaft with
your left hand.
Your left arm should be extended to the most comfortable po-
sition.
Useing the Hedge Trimmer
Preparations
Use lopping shears to cut thick branches first.
Cutting Sequence
If a radial cut is necessary, cut a little at a time in several
passes.
Cutting Techniques
Vertical cut:
Swing the blade up and down in an arc as you move
along the hedge. Use both sides of the cutting blade.
Cut without standing directly next to the hedge, e.g. with
a flower bed between operator and hedge.
Overhead Cut:
Hold the shaft upright with a 90° blade angle to cut an
upper surface of a hedge.
Horizontal Cut:
Hold the cutting blade at an angle of 0° to 10° as you
swing the hedge trimmer horizontally.
Swing the blade in an arc towards the outside of the
hedge so that the cuttings are swept on to the ground.
Cut without standing directly in front of the hedge, e.g.
reach over a flower bed.
Cut close to the ground from a standing position, e.g., for
low shrubs.
22
