Director Mk2 – Quickstart
Power up
12
Turn down the volume of the Director Mk2.
Switch on mains switch on the back of the Director Mk2 (On = I).
13
Power LED is dimly lit.

Operation

Switch the Director Mk2 from standby into operation by setting the standby
14
switch to ON.
Power LED now lights up brightly.
Standby
Switch the Director Mk2 in standby mode by setting the standby switch to
15
( = Standby).
Power LED is dimly lit.

Power down

16
Turn down the volume of the Director Mk2.
Switch off mains switch on the rear of the Director Mk2 (Off = O).
17
Power LED no longer lights up.

Source selection

Choose a source by turning the Source switch: Analog 1 - 6, USB, AES, Coax or
18
Optic.
In Mute position all outputs are switched off.
In Remote position the Director Mk2 receives the commands of any infrared (IR)
remote control to operate the source selection. See next section.
