1. Product description

1.1.

Scope of delivery

1 x power supply unit SKZ 5-01 or SKZ 5-03 or SKZ 5-04 or SKZ 6-00
1 x operating manual
1.2.

Field of application

Installation into the head-end base unit
The power supply units of the SKZ 5-01 and SKZ 5-04 type are suitable for installation into the SKS 40-00 and SKS
4-01 base units. The power supply unit of the SK 6-00 type can be installed into the SKS 8-00 base unit.
Power supply unit
SKZ 5-01
SKZ 5-03*
SKZ 5-04
SKS 6-00
*The SKZ 5-03 power supply unit is not intended for installation into a base unit.
Use as an external device
If necessary, the power supply units may also be operated externally, without installation into a base unit. This
makes it possible to implement tailored and cost-efficient solutions. The head-end cassettes can be used as stand-
alone devices if required.
4 2016-06-01 | © AXING AG Switzerland | We reserve the right not to be liable for any changes in design and layout, errors and misprints
SKS 4-01 SKS 40-00
X
X
Base unit
X
X
SKS 8-00
X
