Operating Instructions for SATA RCS
US
General
■ Comply with local regulations concerning safety, accident prevention,
occupational safety and environmental protection.
■ Observe accident prevention regulations BGR 500.

3. Use

Intended Use
The SATA clean RCS units are used for fast and convenient interim clean-
ing of paint spray guns when changing paints.

4. Description

Fast, claen and convenient interim cleaning of paint spray guns is en-
sured using the compressed-air powered SATA clean RS units.

5. Scope of Delivery

■ SATA clean RCS units, fully pre-assembled.
■ Mounting kit
After unpacking check for:
■ Any damage to SATA clean RCS units
■ Complete scope of delivery

6. Technical Design

SATA clean RCS micro
Air inlet G 1/4 (not shown)
[1-1]
Storage area / cover
[1-2]
"Dry" pushbutton
[1-3]
Dry-blowing nozzle
[1-4]
[1-5] Housing
[1-6] Rinsing connection
Hole for ground connection
[1-7]
Intake hose
[1-8]
Suction tank
[1-9]
SATA clean RCS compact
[2-1] Air inlet G 1/4 (not shown)
[2-2] "Dry" pushbutton
[2-3] Cover / Storage area
Dry-blowing nozzle
[2-4]
Housing
[2-5]
Hole for ground connection
[2-6]
[2-7] Rinsing connection
422
[1-10] Receiver tank
[1-11] Cover plate
[1-12] Cleaning brush
[1-13] Connection for extraction
[1-14] Cleaning nozzle
[1-15] Splash guard
[1-16] "Clean" pushbutton
[1-17] Control module
[2-8] Intake hose
[2-9] Suction tank
[2-10] Receiver tank
[2-11] Cover plate
[2-12] Cleaning brush
[2-13] Cleaning nozzle
[2-14] Connection for extraction
