4.7.1 Authorised sandblasting material
• Cobra (Renfert GmbH)
• Rolloblast (Renfert GmbH)
EN
• ROCATEC (3M ESPE)
Sandblasting materials from other manufacturers may be used providing the grain size, grain shape and
degree of purity comply with the above mentioned materials�
The company Renfert GmbH assumes no liability for function and durability of the units if other sandblast-
ing material is used�
5

Operation

• Switch the illumination on (4)�
If the membrane key is damaged or defect, please discon-
nect the device and send away for repair! If the membrane is
removed there is the risk of an electrical shock!
• Select the blasting tank at the selection switch (1, Fig� 1)�
• Take the respective hand piece from the selected blasting tank
(see coloured marking)�
• Activate the foot switch (20, Fig� 1)�
The sandblasting material will flow as long as the foot switch is
activated�
5.1 Blasting Notes
Flat blasting with wide nozzles:
90003-1739
When blasting glass ceramics, refer to manu facturer's notes�
5.2 Cold silanization in the sandblasting unit
The Basic series of Renfert sandblasting units is exclusively recommended by 3M ESPE for use with
ROCATEC™�
This bonding system is ideal if an adhesive bond is required between a composite and a dental material
(metal, acrylic, porcelain, zirconia porcelain)�
Advantage:
The surface film is applied cold, preventing thermal loading of metal frameworks and consequently the
risk of distortion� All units in the Basic series can be used for ROCATEC™ due to their regular, homoge-
neous jet flow.
6

Cleaning / Maintenance

Before cleaning or servicing:
► Switch off and unplug the device!
► Disconnect the appliance from the compressed air supply!
6.1 Cleaning the Interior
• DO NOT use solvent-containing cleaning agents or disinfec-
tants� (use e�g� soapy water)�
• Remove the grate and vacuum the blasting chamber�
• Wipe out the tanks and lids only with a dry cloth!
1�5 x 3�5 mm [0�059 x 0�138 inch]
- 8 -
4
Fig. 8
Fig. 9
