ICONIQ CF200 Bedienungsanleitung Seite 4

Bedienungsanletung | Users manual
Teileliste
Nr. Beschreibung
1
HOLDER
2
SUPPORT TUBE
3
UPRIGHT TUBE
4
CHIN-UP BAR
5
PIN (SHORT)
6
J-HOOKS
7
EXPANSION SCREW
8
HEXAGON SOCKET CAP BOLT M12*110 + TWO WASHERS 12 + LOCK NUT M12
9
PIN
10
HEXAGON SOCKET CAP BOLT M12*85 + TWO WASHERS 12 + LOCK NUT M12
11
WALL BALL TARGET SUPPORT
12
WALL BALL TARGET
13
TWO WASHERS 10 + LOCK NUT M10
14
HEXAGON SOCKET CAP BOLT M12*130 + TWO WASHERS 12 + LOCK NUT M12
15
Dip Holder
16
FAST PIN
17
SAFETY HOLDER
18
ROTATIONAL CORE
19
BAR HOLDER
20
HEXAGON SOCKET CAP BOLT M10*80 + TWO WASHERS 10 + LOCK NUT M10
Anzahl
4
4
2
1
2
1 Paar
8
4
4
8
1
1
2
2
1 Paar
6
1 Paar
1
1
2
