Step 3: Assembly of the Rotational Core
Nr. Description
1
BAR SUPPORT
2
ROTATIONAL SUPPORT
3
AXIS
4
PLUM SHAPED SCREW
5
NYLON BUSHING
6
LOCK PIN
7
EXAGON SOCKET CAP BOLT M12*105+TWO WASHERS 12+LOCK NUT M12
Quantity
1
1
1
1
1
2
1
