Please note
This product should only be installed be a
suitably qualifi ed electrician or heating installer.
The installation must comply with local Building
Regulations and wiring Regulations, including any
competent person requirements that may exist
Specifi cation
Thermostat features
Temperature range, heating
Temperature range, cooling
Selectable dead-band
Thermostat off/auto & fan on
selector
Power supply
Relay outputs, heat, cool & fan
Dimensions (mm)
Design standard
Rated impulse voltage
Ball hardness test
Control pollution situation
Temperature accuracy
Installation
Instructions
3 x SPST, 3(1)A, 10-230 Vac,
110 wide x 90 high x 40 high
5-30°C
7-32°C at dead-band of 2K
9-34°C at dead-band of 4K
2 or 4K
230 Vac ± 15%, 50/60Hz
Type 1B
EN60730-2-9
2.5Kv
75°C
Degree 2
±1°C
GB
3
