NOTICE
NOTICE NOTICE
To prevent corruption of recordings, the SD card should be unmounted before removal. To
unmount, go to Setup > System Options > Storage > SD Card and click Unmount.
Control button - The control button is used for:
• Resetting the product to factory default settings. See page 25.
• Connecting to an AXIS Video Hosting System service or AXIS Internet Dynamic
DNS Service. For more information about these services, see the User Manual.
Power button - Press and hold the power button to temporarily power the product when the dome
cover is removed. The power button is also used with the control button to reset the camera to
factory default settings. See page 25.
Multi-connector - Terminal connector for connecting external equipment:
• Audio equipment
• Input/Output (I/O) devices
• AC/DC power supply
When connecting external equipment, a multi-connector cable (available from Axis) is required
in order to maintain the product's IP rating. For more information, see Multi-Connector Cable
(sold separately), on page 14.
Multi-Connector Cable (sold separately)
When connecting external equipment to the Axis product, a multi-connector cable (available from
Axis) is required in order to maintain the product's IP rating. The multi-connector cable can be
purchased from your Axis reseller.
Connect the multi-connector cable to the product's multi-connector. To locate the multi-connector,
see Hardware Overview, on page 10. The cable provides the following connectors:
Power connector - 3-pin terminal block used for power input. See image below. Use a limited
power source (LPS) with either a rated output power limited to ≤100 W or a rated output current
limited to ≤5 A.
Audio in (pink) - 3.5 mm input for a mono microphone, or a line-in mono signal (left channel is
used from a stereo signal).
Audio out (green) - 3.5 mm output for audio (line level) that can be connected to a public address
(PA) system or an active speaker with a built-in amplifier. A stereo connector must be used for the
audio out.
I/O terminal connector - Use with external devices in combination with, for example, tampering
alarms, motion detection, event triggering, time lapse recording and alarm notifications. In addition
to ground and auxiliary power, the I/O terminal connector provides the interface to:
