Electrical Specifications - Klein Tools CL900E Gebrauchsanleitung

Function
AC voltage
(V AC)
DC voltage
(V DC)
Input impedance: 10 MΩ
Maximum input: 1,000 V AC RMS or 1,000 V DC
*Accuracy specified from 5% to 100% of the measuring range
AC current
(A) TRMS
DC current (A)
AC frequency range: 50 to 60 Hz, >500 mA
DC: >200 mA (low current requires use of the DC ZERO function)
AC current (A)
inrush
AC frequency range: 50 to 60 Hz
**Accuracy specified assumes an AC sine wave
Resistance
Maximum input: 600 V AC RMS or 600 V DC
Capacitance
Maximum input: 600 V AC RMS or 600 V DC

ELECTRICAL SPECIFICATIONS

Range
600.0 mV
6.000 V
60.00 V
600.0 V
1000 V
600.0 mV
6.000 V
60.00 V
600.0 V
1000 V
Frequency range: 50 to 400 Hz
600.0 A
2,000 A
600.0 A
2,000 A
600 A
2,000 A
when auto-ranging >3 A detectable
(>2A if held in 600 A range)
600.0 Ω
6.000 KΩ
60.00 kΩ
600.0 kΩ
6.000 MΩ
60.00 MΩ
60.00 nF
600.0 nF
6.000 µF
60.00 µF
600.0 µF
6,000 µF
Resolution Accuracy (50/60 Hz)
0.1 mV
1 mV
10 mV
0.1 V
1 V
0.1 mV
1 mV
10 mV
0.1 V
1 V
0.1 A
1 A
0.1 A
1A
0.1 A ±(2.5% + 5 digits)**
1A ±(3.0% + 8 digits)**
0.1 Ω
1 Ω
10 Ω
100 Ω
1 kΩ
10 kΩ
10 pF
0.1 nF
1 nF
10 nF
0.1 µF
1 µF
±(1.0% + 8 digits)*
±(1.0% + 5 digits)
±(1.2% + 5 digits)
±(1.5% + 5 digits)
±(0.9% + 8 digits)
±(1.0% + 3 digits)
±(1.2% + 3 digits)
±(2.0% + 5 digits)
±(2.5% + 8 digits)
±(2.0% + 5 digits)
±(2.5% + 8 digits)
±(1.5% + 5 digits)
±(2.0% + 10 digits)
±(5.0% + 35 digits)
±(3.0% + 5 digits)
±(5.0% + 5 digits)
3
