Connection with the mains

Connect the device to the mains with the enclosed power supply cable.
The occupation of the connection-cables is as follows:
Cable Pin
Brown Live
Blue Neutral
Yellow/Green Earth
The earth has to be connected!
If the device will be directly connected with the local power supply network, a disconnection switch with a
minimum opening of 3 mm at every pole has to be included in the permanent electrical installation.
The device must only be connected with an electric installation carried out in compliance with the IEC-
standards. The electric installation must be equipped with a Residual Current Device (RCD) with a maximum
fault current of 30 mA.
Lighting effects must not be connected to dimming-packs.
The device is equipped with a lockable power input connector. Plug in the power cord and turn it to the right
until it locks. Plug the power cord into a grounded electrical outlet that matches the rated voltage of the
machine.

Connection between devices

On the rear panel, there is a socket (Power Out). Connect the output with the mains input of the next fixture
until all fixtures are connected.
Please note: A maximum of 8 devices may be linked together. After every 8 devices, the fixtures must have

OPERATION

With the power switch, you can switch the device on and off.
After you connected the effect to the mains, the DMH-75 Infinity starts running. During the reset, the motors
are trimmed and the device is ready for use afterwards.
By turning the setting ring of the lens, the beam angle can be set between 13° and 18°.

Stand Alone operation

In the Stand Alone mode, the DMH-75 Infinity can be used without controller. Disconnect the DMH-75 Infinity
from the controller and call the internal program. Please refer to the instructions under Control Board.

DMX-controlled operation

You can control the projectors individually via your DMX-controller. Every DMX-channel has a different
occupation with different features. The individual channels and their features are listed under DMX-protocol.

Addressing

The Control Board allows you to assign the DMX starting address, which is defined as the first channel from
which the DMH-75 Infinity will respond to the controller.
International
L
N
a renewed connection with the power mains.
39/54 00081673.DOC, Version 1.0
