as full screen pictures. The following switching function
is performed:
Quad splitter display (button QUAD)
Full screen camera channel 1 (button
Full screen camera channel 2 (button
Full screen camera channel 3 (button
Full screen camera channel 4 (button
Then the process will be repeated. The dwell time of
the pictures is 4 seconds. Camera channels which are
not connected are displayed as grey area.
5.3 Manual selection and switching of the
cameras
If a camera picture is permanently to be displayed on
the monitor, press the corresponding button (3). The
camera picture is displayed as full screen picture on
the monitor. To switch to another camera picture, press
the corresponding button of the camera input.

6 Specifications

Video
Signal format: . . . . . . . . . . CCIR
Camera inputs: . . . . . . . . . 1 Vpp/75Ω, adjustable
Outputs: . . . . . . . . . . . . . . 1 Vpp/75 Ω
Resolution: . . . . . . . . . . . . 1024 x 512 pixels,
Switching interval: . . . . . . . 4 s
General information
Ambient temperature: . . . . 0 – 40 °C
Power supply: . . . . . . . . . . 12 V
Dimensions (W x H x D): . . 220 x 50 x 215 mm
Weight: . . . . . . . . . . . . . . . 1.2 kg
Connections
Camera inputs: . . . . . . . . . 4 x BNC
Monitor output: . . . . . . . . . 1 x BNC for split or
2nd video output: . . . . . . . 1 x BNC for permanent
Power supply: . . . . . . . . . . 1 x low voltage jack
According to the manufacturer.
Subject to technical change.
)
)
)
)
8 bits = 256 grey scales
(regulated),
200 mA
full screen display
split display
(5.5/2.1 mm)
