Installation of camera drivers and software

1. Operating system requirements: all the Windows O.S.
2. Please insert your CD and run:
\optika vision lite\ setup.exe
3. Now the Optika Vision Lite icon appears on your desktop.
4. You don't need to install any driver.
5. Plug the Camera in your PC: the camera will be identified automatically.

How to test your Camera

In order to check if your Camera works correctly, it's not necessary to put it into the microscope: it's enough to
connect it into the USB port, run Vision Lite using the icon on your desktop, select the right driver and check
whether the shown image is not totally black.

Select the right driver

Please select: USB VIDEO DEVICE.
With Optika Vision Lite you have to tell the Software which is the Driver by selecting the microscope-shaped
icon. With Optika IsView the live image coming from your camera will automatically appear.
Getting started with Optika Vision Lite, a very easy measuring and documentation
software.
Run Optika Vision Lite by clicking on its icon on your desktop.
Select the right Driver for capturing the image. Note that after choosing the driver and before capturing the image
you can set the brightness, saturation, gamma ecc..
Then you can capture the image.
The image is now ready for being manipulated using Optika Vision Lite.
