EDUCAM MULTIMEDIA INSTRUCTION MANUAL Model 4083 4083.1 Version: Issued: 04, 09, 2014...
Seite 2
Description The EDUCAM MULTIMEDIA video camera is especially designed to meet the various requirements in the edu- cational field. When it is connected to a professional monitor or simply to a TV set, EDUCAM is able to carry out many different functions. It can be used in the following ways: as an episcope, for the reproduction of texts, documents, photographs, etc.
Seite 3
Overview HEAD OBJECTIVE HEAD ROTATION SYSTEM FLEXIBLE ARM VIDEO/ AUDIO SWITCH MICROPHONE POWER SOCKET VIDEO/AUDIO LED VIDEO/AUDIO AV SIGNAL CABLE BASE VIDEO USB SIGNAL CABLE Page 3...
Power supply The Educam Multimedia video camera requires 15 V DC working voltage and comes with an external power pack. This power pack needs to be plugged directly into a 220 V mains sockets and its output cable should then be plugged directly into the video camera power supply socket.
Operation Switching on the video camera The Educam video camera has a 3-position switch at the rear of its base. Each position corresponds to a spe- cific function: Central position “0” -> TV camera off. Position “I” -> the yellow LED is lit and the Educam is operating with video signal only. Position “II”...
Equipment disposal Art.13 Dlsg 25 july 2005 N°151. “According to directives 2002/95/EC, 2002/96/EC and 2003/108/EC relating to the reduction in the use of hazardous substances in electrical and electronic equipment and waste disposal.” The basket symbol on equipment or on its box indicates that the product at the end of its useful life should be collected separately from other waste.
EDUCAM MULTIMEDIA MANUALE D’ISTRUZIONI Modello 4083 4083.1 Versione: 2 Emesso il: 04, 09, 2014 Pagina 7...
Seite 8
La telecamera EDUCAM è uno strumento espressamente progettato per soddisfare molteplici esigenze in ambi- to didattico. La telecamera EDUCAM MULTIMEDIA è uno strumento espressamente progettato per soddisfare molteplici esigenze in ambito didattico. Collegata ad un monitor professionale o semplicemente ad un apparec- chio televisivo, EDUCAM svolge il lavoro di molteplici apparecchi.
Descrizione dello strumento TESTATA OBIETTIVO SISTEMA DI ROTAZIONE DELLA TESTA BRACCIO FLESSIBILE INTERRUTTORE AUDIO/VIDEO MICROFONO PRESA DI ALIMENTAZIONE INDICATORE LED CAVO SEGNALE AUDIO/VIDEO AV VIDEO/AUDIO BASE CAVO SEGNALE VIDEO Pagina 9...
Specifiche tecniche Sensore 1/3” transfer interlinea a colori elemento CCD Risoluzione orizzontale 420 linee TV Pixel totali 244 k pixel Obiettivo 8 mm, F:1.2 Sensibilità min. 0,08 lux at F:1.2 Controllo immagini shutter elettronico Controllo guadagno automatico Bilanciamento del bianco automatico Segnale video compatibile PAL –...
Funzionamento Utilizzo della telecamera Per mezzo del braccio flessibile, posizionare la testata della telecamera in modo che la lente e il sensore elet- tronico si trovino direttamente di fronte all’oggetto che si vuole osservare. La lente fornita in dotazione ha una regolazione manuale della messa a fuoco ed è quindi necessario regolare la messa a fuoco ogni volta che si varia la distanza fra oggetto e telecamera.
Seite 12
Smaltimento Ai sensi dell’articolo 13 del decreto legislativo 25 luglio 2005 n°151. “Attuazione delle direttive 2002/95/CE, 2002/96/CE e 2003/108/CE, relative alla riduzione dell’uso di sostanze pericolose nelle apparecchiature elettriche ed elettroniche, nonché allo smaltimento dei rifiuti”. Il simbolo del cassonetto riportato sulla apparecchiatura o sulla sua confezione indica che il prodotto alla fine della propria vita utile deve essere raccolto separatamente degli altri rifiuti.
Seite 13
EDUCAM STUDENT MANUAL DE INSTRUCCIONES Modelo 4083 4083.1 Versión: Publicado: 04, 09, 2014 Página 13...
Seite 14
Descripción Las tele cámaras EDUCAM son instrumentos expresamente diseñados para satisfacer múltiples exigencias en el ámbito didáctico. Conectadas a un monitor profesional o simplemente a un TV de color, las tele cámaras Educam realizan el trabajo de varios aparatos. Estas pueden ser usadas para las siguientes aplicaciones: como episcopio para la reproducción de textos, documentos, fotografías, etc...;...
Vista general CABEZAL OBJETIVO SISTEMA DE ROTACIÓN DEL CABEZAL BRAZO FLEXO BOTON ENCENDIDO VIDEO/AUDIO MICROFONO CONECTOR CABLE ELÉCTRICO LED DE VIDEO/AUDIO CABLE SEÑAL VIDEO/AUDIO AV LED DE LA BASE CABLE SEÑAL VIDEO USB Página 15...
Montaje Alimentación La video cámara EDUCAM MULTIMEDIA requiere un voltaje de 15V DC. Se suministra con un transformador externo. Dicho transformador está listo para conectarse a una corriente eléctrica de 220V. Conectar el tranfor- mador me diante su cable al “jack” de la video cámara para ello.
Seite 17
Utilización de la video cámara Colocar la cámara con su lente directamente frente al objeto que desea observar, con la ayuda del brazo flexo. La lente suministrada con la cámara es de enfoque manual y por lo tanto será necesario ajustar la distancia cada vez que sea necesario.
Eliminación de residuos En conformidad con el Art. 13 del D.L. de 25 julio 2005 n°151. Actuación de las Directivas 2002/95/CE, 2002/96/ CE y 2003/108/CE, relativas a la reducción del uso de sustancias peligrosas en la instrumentación eléctrica y electrónica y a la eliminación de residuos. El símbolo del contenedor que se muestra en la instrumentación o en su embalaje indica que el producto cuando alcanzará...
Seite 19
EDUCAM MULTIMEDIA BEDIENUNGSANLEITUNG Modell 4083 4083.1 Version: Datum: 04, 09, 2014 Pagina 19...
Seite 20
Beschreibung Die EDUCAM Kamera wurde entwickelt, um verschiedene Bedürfnisse im Bereich der Didaktik zu erfüllen. Wenn sie an einem professionellen Monitor oder einfach an einem Fernsehgerät verbunden ist, kann EDUCAM MULTIMEDIA unterschiedliche Funktionen erledigen. Sie kann für folgende Anwendungen verwendet werden: als Episkop zur Wiedergabe von Texten, Dokumenten, Fotos, usw;...
Seite 21
Beschreibung KAMERAKOPF OBJEKTIV DREHGELENK FLEXIBLER ARM AUDIO / VIDEO SCHALTER MIKROFON AUSGANG VERSORGUNG VIDEO/AUDIO-LED NETZKABELANSCHLUSS KAMERAFUSS AUDIO/VIDEO-KABEL Pagina 21 Pagina 21...
3.4 Kg Bedienung Netzsteckeradapter Die Educam Multimedia Kamera benötigt eine 15 V DC Spannung und ist mit einem Außennetzteil ausgestattet. Der Außennetzteil muss direkt in die 220 V Steckdose und der Ausgangskabel muss in die Netzstecker der Kamera eingesetzt werden.
Betrieb Gebrauch Mittels des flexiblen Arm positionieren Sie den Kamerakopf so dass die Linse und der elektronische Sensor direkt dem Objekt gegenüber sind, das man beobachten möchte. Die mitgelieferte Linse hat eine manuelle Scharfstellung. Jedes Mal, wenn die Distanz zwischen Objekt und Kamera sich geändert hat, sollen Sie durch Drehung der Linse an dem Kamerakopf neu nachfokussieren.
Seite 24
Wiederverwertung Gemäß dem Artikel 13 vom Dekret Nr. 151 vom 25.07.2005 “Umsetzung der Richtlinien 2002/95/EG, 2002/96/EG und 2003/108/EG in Bezug auf die Verwendung gefährlicher Stoffe in elektrischen und elektronischen Geräten sowie die Abfallentsorgung” Das Symbol vom Müllcontainer erscheint auf dem Gerät oder der Verpackung und weist darauf hin, dass das Produkt Ende des Lebens separat von anderen Abfällen entsorgt werden muss.
