1) Select the operating mode of the receiver with the
DIP switch M/L (11):
Position M = manual channel selection: Adjust the
desired transmission channel with the button (9).
Position L = automatic channel selection for re-
ceiving the signals of several cameras: Every 4 sec-
onds, the receiver will switch between the channels
of which the DIP switches (11) are set to ON; the
other channels will be skipped. The LEDs (10) of the
channels used will light up. The LED of the channel
received at the moment will flash.
2) Adjust the transmitter to the corresponding channel
with the switch Channel (5).
3) In case of interference occurring on the selected
channel, select another transmission channel at the
receiver and at the transmitter.
All rights reserved by MONACOR
GmbH & Co. KG. No part of this instruction manual may be
repro duced in any form or by any means for any commer-
cial use.
5
Transmitter
Transmitting power: . . . . . . . . < 10 mW (EIRP)
Range
Video input: . . . . . . . . . . . . . . 1 Vpp, 75 Ω, BNC
Audio signal: . . . . . . . . . . . . . from the integrated micro-
Power supply: . . . . . . . . . . . . 12 V , 50 mA
Dimensions (without antenna): 36.5 × 40.5 × 34.5 mm
Weight: . . . . . . . . . . . . . . . . . . 25 g
Receiver
Video output: . . . . . . . . . . . . . 1 Vpp, 75 Ω
Audio output: . . . . . . . . . . . . . 1 Vpp, 600 Ω
Power supply: . . . . . . . . . . . . 8 V , 180 mA
Dimensions (without antenna): 68 x 18 x 86 mm
Weight: . . . . . . . . . . . . . . . . . . 130 g
Common specifications
Transmitting frequencies: . . . . channel 1
Antenna: . . . . . . . . . . . . . . . . omnidirectional antenna
® INTERNATIONAL Modulation/demodulation: . . . FM
Ambient temperature: . . . . . .
Subject to technical modification.

Specifications

without any obstacles: . . . . up to 100 m
in buildings . . . . . . . . . . . . up to 20 m
phone
2.414 GHz
channel 2 2.432 GHz
channel 3 2.450 GHz
channel 4 2.468 GHz
-
10 °C to +50 °C
