Care & Cleaning - RUSTA 907512020101 Gebrauchsanleitung

ENG
5. Loosen fan blade locking screw (C). Insert and slide fan blade assembly (B) onto fan
motor shaft (G) until the blade rests again the shaft pin. Screw on and tighten fan
blade locking screw (C) by turning counter-clockwise (to the left) direction.
6. Open all grill clasps (F) on front grill (A). Remove safety screw (W) from bottom of front
grill (A) and place aside momentarily. Position frill clip at the top center of rear grill
(F) and secure all grill clasps (F) are closed. So the front and rear grills are pressed
together. Re-attach safety screw (W) and secure.
FAN USE
1. The speed selector switch is located on the back of the motor housing. To operate, sim-
ply twist the knob to the desired setting. Your fan features 3 speed settings (l - Lowest
Speed, II - Medium Speed, IIJ - Highest Speed). 0 - Fan is turned off.
2. The fan can operate in a stationary or an oscillating mode. To shift between modes,
simply pull up or depress the Oscillation Button located next to the speed switch on the
fan motor.
3. You can adjust the angle of your fan by adjusting the tilt adjustment screw underneath
the fan motor at the base. Be sure to firmly tighten the screw when the desired angle is
achieved.
CARE & CLEANING
1. Always turn your fan to the off position prior to cleaning.
2. Clean parts with a duster or damp cloth. Prior to resuming use, make sure all moisture
is dry.
3. Do not immerse in any type of liquid or use abrasive cleaning solutions.
4. Use care around the motor housing as no excessive moisture or liquid should come in
contact with the motor housing or its parts.
5. When storing your fan, make sure to place in a dry environment. To reduce dust and
particle exposure, it is best to cover your fan - especially in the off-season period.
4
