Revisions to the Operating Instructions
Be sure to read these revisions before installing the product.
Before revision
Accessories of speaker box
(S-BD919HW/S-BD91HW)
Non-skid pads (2)
Speaker Setup
Preparing the speakers
1 Attach the non-skid pads to the base of each speaker.
For front speaker:
Use the supplied adhesive to attach two pads
to the base (bottom) of speaker.
Non-skid pads
Wall mounting the speaker
1 Use a Phillips screwdriver to remove the two screws
holding the stands to the speaker.
BCS-HW919/HTZ-BD91HW/HTZ-HW919BD
After revision
Accessories of speaker box
(S-BD919HW/S-BD91HW)
Non-skid pads (6)
Speaker Setup
Preparing the speakers
1 Attach the non-skid pads to the base of each speaker.
For front speaker:
Use the supplied adhesive to attach six pads
to the base (bottom) of speaker.
Affix to
three locations
Non-skid pad
(for front)
Wall mounting the speaker
1 Remove the base plates.
The base plates are held in position by the use of 2-sided
tape. While holding the leg in place, strongly press the
base plate in the direction indicated by the arrow to
remove the base plate. Be careful not to damage the
front speaker while doing this.
2 Use a Phillips screwdriver to remove the two screws
holding the legs to the speaker.
Non-skid pad
(for front)
Base plate
Leg

Werbung

Inhaltsverzeichnis
loading

Inhaltszusammenfassung für Pioneer BCS-HW919

  • Seite 1 BCS-HW919/HTZ-BD91HW/HTZ-HW919BD Revisions to the Operating Instructions Be sure to read these revisions before installing the product. Before revision After revision Accessories of speaker box Accessories of speaker box (S-BD919HW/S-BD91HW) (S-BD919HW/S-BD91HW) Non-skid pads (2) Non-skid pads (6) Speaker Setup Speaker Setup...
  • Seite 2: Installation Precautions

    When installing the speaker, orient the unit so that front speaker’s top edge is pointed up, then bring it closer to the television screen so that the Pioneer logo is oriented as shown in the accompanying illustration.
  • Seite 3 BCS-HW919/HTZ-BD91HW/HTZ-HW919BD Révisions des instructions de fonctionnement Veillez à lire ces révisions avant d’installer l’appareil. Avant la révision Après la révision Accessoires du boîtier du haut-parleur Accessoires du boîtier du haut-parleur (S-BD919HW/S-BD91HW) (S-BD919HW/S-BD91HW) Tampons antidérapants (2) Tampons antidérapants (6) Montage des haut-parleurs Montage des haut-parleurs Préparation des haut-parleurs...
  • Seite 4: Caractéristiques

    à Sound Wing. Lors de l’installation du haut-parleur, orientez l’appareil de sorte que l’arête supérieure du haut-parleur avant pointe vers le haut, puis approchez-le de l’écran du téléviseur de sorte que le logo Pioneer soit orienté comme indiqué sur l’illustration ci-joint.
  • Seite 5 BCS-HW919/HTZ-BD91HW/HTZ-HW919BD Revision der Bedienungsanleitung Bitte lesen Sie vor der Installation des Gerätes unbedingt die folgenden Revisionen. Vor Revision Nach Revision Lautsprecherzubehör Lautsprecherzubehör (S-BD919HW/S-BD91HW) (S-BD919HW/S-BD91HW) Rutschfeste Unterlagen (2) Rutschfeste Unterlagen (6) Einrichtung der Lautsprecher Einrichtung der Lautsprecher Vorbereitung der Lautsprecher Vorbereitung der Lautsprecher...
  • Seite 6: Technische Daten

    • Der Frontlautsprecher sollte so aufgestellt werden, dass er den Ton vom Fernsehschirm refl ektiert, damit das für Sound Wing charakteristische breite Klangbild erzeugt wird. Stellen Sie den Frontlautsprecher so auf, dass seine Vorderkante nach oben weist, und bringen Sie ihn dann näher an das Fernsehgerät heran, so dass der Pioneer-Schriftzug wie in der Abbildung gezeigt ausgerichtet ist.
  • Seite 7 BCS-HW919/HTZ-BD91HW/HTZ-HW919BD Revisioni alle istruzioni per l’uso Prima di installare il prodotto, non mancare di leggere le seguenti revisioni. Prima della revisione Dopo la revisione Accessori della cassa dell’altoparlante Accessori della cassa dell’altoparlante (S-BD919HW/S-BD91HW) (S-BD919HW/S-BD91HW) Piedini antiscivolo (2) Piedini antiscivolo (6)
  • Seite 8: Specifiche Tecniche

    Sound Wing. Nell’installare il diffusore, orientare questa unità in modo che il bordo superiore del diffusore anteriore sia rivolto in su, poi avvicinarlo allo schermo del televisore in modo che il logo Pioneer sia orientato nel modo visto nell’illustrazione qui accanto.
  • Seite 9 BCS-HW919/HTZ-BD91HW/HTZ-HW919BD Revisiones del Manual de instrucciones Lea sin falta estas revisiones antes de efectuar la instalación del producto. Antes de la revisión Después de la revisión Accesorios y cajas de altavoces Accesorios y cajas de altavoces (S-BD919HW/S-BD91HW) (S-BD919HW/S-BD91HW) Apoyos antideslizantes (2) Apoyos antideslizantes (6) Confi...
  • Seite 10: Especificaciones

    Pioneer esté situado como se muestra en la ilustración siguiente. • No se suba encima del altavoz ni lo cuelgue de ningún otro objeto, porque podría caerse o resultar dañado. Tenga...
  • Seite 11 BCS-HW919/HTZ-BD91HW/HTZ-HW919BD Wijzigingen in de handleiding Lees deze wijzigingen zorgvuldig door voordat u het product installeert. Vóór de wijziging Na de wijziging Toebehoren voor luidsprekerbox Toebehoren voor luidsprekerbox (S-BD919HW/S-BD91HW) (S-BD919HW/S-BD91HW) Antislipkussentjes (2) Antislipkussentjes (6) Luidsprekers instellen Luidsprekers instellen De luidsprekers voorbereiden...
  • Seite 12: Voorzorgsmaatregelen Bij De Installatie

    Pioneer-logo in de stand is aangegeven in de afbeelding. • Ga niet op de luidspreker staan en hang deze niet aan een ander voorwerp, want de luidspreker kan vallen of beschadigd...
  • Seite 13 BCS-HW919/HTZ-BD91HW/HTZ-HW919BD 操作手冊修訂版 安裝本產品之前, 請務必閱讀操作手冊修訂版。 修訂前 修訂後 揚聲器音箱之配件 揚聲器音箱之配件 (S-BD919HW/S-BD91HW) (S-BD919HW/S-BD91HW) 防滑墊 (2) 防滑墊 (6) 揚聲器設定 揚聲器設定 準備揚聲器 準備揚聲器 1 把防滑墊貼附在每個揚聲器的底部。 1 把防滑墊貼附在每個揚聲器的底部。 前置揚聲器 : 前置揚聲器 : 使用隨附的黏貼, 把 2 個防滑墊貼在每個揚聲器的底部。 使用隨附的黏貼, 把 2 個防滑墊貼在每個揚聲器的底部。 把揚聲器掛牆安裝 把揚聲器掛牆安裝 1 使用 Phillips 的螺絲刀移除揚聲器底座上的兩顆螺絲。...
  • Seite 14 修訂前 修訂後 規格 規格 喇叭 BCS-HW919/HTZ-BD91HW/HTZ-HW919BD 喇叭 BCS-HW919/HTZ-BD91HW/HTZ-HW919BD S-BD919HW/S-BD91HW S-BD919HW/S-BD91HW • 前置揚聲器 • 前置揚聲器 淨尺寸 (W x H x D) ......... 900 x 66 x 93 公釐 淨尺寸 (W x H x D) ......... 900 x 71 x 93 公釐...
