5.5 Returning to a saved Focus Position
If you are in normal mode (LED 1 and 2 are off):
1. Push and hold JOG
for three seconds. Now, the focuser moves to the
stored position.
Over time, small errors caused by slippage may add up. We recommend that
you move the focuser to the zero position defined by the homing sensor before
you move it to a stored position.
5.6 Activating and Deactivating the Temperature Compensation
The automatic temperature compensation must be configurated through the
SteelGo II sonftware and a PC. It can only be turned on or off with the key pad
of the controller.
•
Activate: When in normal mode (all LEDs are off), push and hold SET
for three seconds. Now, LED 2 is blinking slowly.
•
Deactivate: Once the temperature compensation is active (LED 2 is
blinking slowly) and you are in normal mode, you can turn it off by pushing
and holding SET
for three seconds. Then, LED 2 will go off.
Overview of the functions of the SD II Controller – printed on the back of the controller.
22
Manual: Steeldrive II Motor Unit
5.7 Override-Limits-Mode
If necessary, you can ignore the limits which are set in the Steeldrive II. This is
e.g. useful if you want to set a new outer limit, which is farther outwards than
the current one.
1. When in normal mode, push SET
2. Now hold SET
for three seconds, until LED 2 flashes fast.
3. Now you can move the focuser with IN
4. To leave the override-limits-mode, hold SET
to normal mode, until LED 2 goes out.
If desired, you can save the new outer limit (see 5.2).
5.8 Overview of the Functions of the SD II Controller
Normal-Mode
Settings-Mode
(LED 2 active)
Move outwards
Save outer limit
OUT
(hold 3 s)
Move inwards
Set or GoTo
IN
zero position
(hold 3 s)
Switch to
Save position/
JOG
focus
JOG-Mode
(hold 3 s)
Switch to SET-
Exit SET-Mode
SET
TINGS-Mode
----------------
----------------
Activate Overri-
Temperature-
de-Limits-Mode
Compensation
(hold 3 s)
on/off
(hold 3 s)
once until LED 2 lights up.
and OUT
to a new limit.
for three seconds to return
JOG-Mode
Single-Step-
(LED 1 active)
Mode
(LED 1+2 active)
Jog outwards
Single step
outwards
Jog inwards
Single step
inwards
Exit JOG-Mode
Switch to
NORMAL-Mode
Switch to
Switch to
SINGLE-STEP-
JOG-Mode
Mode
© Baader Planetarium GmbH | 2019
23
